AGV Communication Battery

Specifications

Item	Specification
Product	AGV Communication Battery
Cell Model	18650 / 2500mAh / 3.6V
Battery Configuration	25.9V‑10Ah
Product Dimension	169.5×71×35.6mm
Nominal Voltage	25.9V
Nominal Capacity	10Ah
Charging Voltage	29.4V
Charging Current	3.2A
Continuous Discharge Current	8.4A
Discharge Cut‑off Voltage	17.5V
Finished‑product Internal Resistance	≤200mΩ
Battery Weight	About 900g
Charging Temperature	0 ~ 45℃
Discharging Temperature	-20 ~ 60℃
Storage Temperature	-20 ~ +50℃ (＜1 month); ‑20 ~ 40℃ (＜3 months); ‑20 ~ +20℃ (＜12 months)
Battery Casing	Stainless steel housing
BMS Protection	Short‑circuit protection, over‑charge protection, over‑discharge protection, over‑current protection, over‑temperature protection, etc.
Application Fields	Communication equipment
