Mobile Robot

Specifications

Product Specification Sheet

Parameter	Specification
Cell Model	18650 / 3.7V / 2.5Ah
Battery Configuration	18650-7S16P / 25.9V / 40Ah
Nominal Voltage	25.9 V
Nominal Capacity	40 Ah
Charge Voltage	29.4 V
Charge Current	≤ 10 A
Discharge Current	10 A
Instantaneous Discharge Current	35 A
Discharge Cut-off Voltage	19.6 V
Internal Resistance (Finished)	≤ 200 mΩ
Battery Weight	6.0 kg
Product Dimensions (L×W×H)	260 × 170 × 90 mm (Max)
Charging Temperature	0℃ ~ 45℃
Discharging Temperature	-20℃ ~ 50℃
Storage Temperature	-20℃ ~ 40℃
Temperature Protection	65℃ ± 5℃
Battery Enclosure	Cold-rolled sheet metal
Protection Features	Short circuit protection, overcharge protection, over-discharge protection, overcurrent protection, temperature protection, and more
Application Fields	Robotics, AGV (Automated Guided Vehicles), and more

Product Features:

Shock & Vibration Resistant: Cold-rolled sheet metal housing with internal shock-absorbing structure design ensures high safety and reliability in demanding mobile applications
High-Current Output Capability: Supports up to 3C continuous discharge for high-power demand applications
Intelligent Data Communication Management: Advanced software management chip enables precise data transmission and accurate temperature control, effectively minimizing potential safety risks
Automatic Temperature Protection: Integrated temperature sensor triggers automatic protection when temperature exceeds preset threshold
Long Cycle Life: Extended operational lifespan reduces total cost of ownership
Environmentally Friendly: Long cycle life aligns with low-carbon, energy-saving, and sustainable value propositions
