Specifications

Product Specification Sheet

Parameter	Specification
Cell Model	26700-4000mAh-3.2V
Battery Configuration	26700-12S8P-32Ah-38.4V
Product Dimensions (L×W×H)	320 × 220 × 125 mm
Nominal Voltage	38.4 V
Nominal Capacity	32 Ah
Internal Resistance (Finished)	≤ 200 mΩ
Charge Voltage	43.8 V
Charge Current	≤ 10 A
Discharge Current	≤ 30 A
Discharge Cut-off Voltage	24 V
Battery Weight	2.5 kg
Charging Temperature	0℃ ~ 45℃
Discharging Temperature	-20℃ ~ 60℃
Storage Temperature	-20℃ ~ 35℃
Battery Enclosure	Aluminum alloy housing
Protection Features	Short circuit protection, overcharge protection, over-discharge protection, over-temperature protection, overcurrent protection, ESD protection, and more
Application Fields	Disinfection / sanitization robots, AGV (Automated Guided Vehicles), energy storage equipment, robotics, and more

Product Features:

Durable Enclosure: Aluminum alloy housing provides enhanced reliability and structural strength
Superior Shock & Vibration Resistance: Cell holder frame with epoxy board insulation and dedicated nickel strip connections ensure excellent anti-vibration and anti-shock performance
High-Reliability Output: XT60 connector with plug-and-play design ensures secure and reliable conductive connections
Comprehensive Protection Management: Utilizes specialized lithium battery protection ICs with high stability, precise monitoring, and accurate control, including temperature protection to eliminate potential safety hazards
Data Communication Management: Supports both RS485 and CAN bus for precise data transmission, accurate temperature control, and real-time battery status monitoring, effectively minimizing potential safety risks
Isolated Communication: BMS communication features optocoupler isolation for enhanced noise immunity; supports RS485 network connectivity at 9600 bps baud rate
High Performance: Safe and reliable discharge performance with extended cycle life
