Robot Car

Specifications

Product Specification Sheet

Parameter	Specification
Cell Model	26700 / 3.2V / 4Ah
Battery Configuration	26700-16S6P / 48V / 20Ah
Nominal Voltage	48 V
Nominal Capacity	24 Ah
Charge Voltage	58.4 V
Charge Current	≤ 10 A
Discharge Current	20 A
Instantaneous Discharge Current	50 A
Discharge Cut-off Voltage	40 V
Internal Resistance (Finished)	≤ 200 mΩ
Battery Weight	15 kg
Product Dimensions (L×W×H)	300 × 237 × 165 mm (Max)
Charging Temperature	0℃ ~ 45℃
Discharging Temperature	-20℃ ~ 60℃
Storage Temperature	-20℃ ~ 60℃
Temperature Protection	65℃ ± 5℃
Battery Enclosure	Cold-rolled steel plate + powder coating
Protection Features	Short circuit protection, overcharge protection, over-discharge protection, overcurrent protection, temperature protection, RS485 communication
Application Fields	Wide range of applications, including industrial machinery and equipment, AGV (Automated Guided Vehicles), and more

Product Features:

Communication Function: Equipped with LCD display for real-time voltage and battery level indication for user-friendly monitoring
Terminal Output: Heavy-duty binding-post output terminals ensure reliable and secure conductive connections
Data Communication Management: Utilizes high-precision Seiko IC and TI charger management chips for accurate data transmission and precise temperature control, minimizing potential safety risks
Safe & Portable: Features a dedicated ergonomic handle for easy lifting and transport
Low-Temperature Performance: Excellent discharge characteristics in cold environments
Long Cycle Life: Extended operational lifespan for reduced total cost of ownership
Environmentally Friendly: High cycle life aligns with low-carbon, energy-saving, and sustainable value propositions
