Sodium-ion Layered Oxide BN Series

Specifications

Here is the English version of the third table, formatted for easy copying into Excel or a document:

Model	D50 (μm)	TD (g/cm³)	SSA (m²/g)	Residual Alkali (wt%)	Specific Capacity 0.1C (mAh/g)	Mid-V (V)	DC Retention @ -20°C (%)	Cycle Life =80%
BNH-O3A	11.0 ± 1.0	≥ 1.9	≤ 0.5	< 0.4	138 ± 2 (2.0-4.0V)	3.0	90.0	≥ 2000
BNS-O3B	7.0 ± 1.0	≥ 1.5	≤ 0.5	< 0.6	151 ± 2 (2.0-4.1V)	3.1	90.0	≥ 2000
BNS-P2C	8.0 ± 1.0	≥ 1.5	≤ 0.5	< 0.4	125 ± 2 (2.0-4.1V)	3.3	91.3	≥ 4000
BNH-P2B	6.0 ± 1.0	≥ 1.6	≤ 0.5	< 0.4	115 ± 2 (2.0-4.3V)	3.6	90.5	≥ 10000

Key for Abbreviations:

D50: Median Particle Size
TD: Tap Density
SSA: Specific Surface Area
Mid-V: Midpoint Voltage
DC Retention: Low-temperature Discharge Capacity Retention
Cycle Life =80%: Number of cycles until capacity drops to 80% of initial value
