Solar Panel Cleaning Robot

Specifications

Product Specification Sheet

Parameter	Specification
Cell Model	LFP100-3.2V
Battery Configuration	LFP100-16S1P-100Ah-48V
Product Dimensions (L×W×H)	470 × 430 × 277 mm (Max)
Nominal Voltage	51.2 V
Nominal Capacity	100 Ah
Internal Resistance (Finished)	≤ 150 mΩ
Charge Voltage	58.4 V
Charge Current	≤ 47 A
Discharge Current	≤ 100 A
Discharge Cut-off Voltage	40 V
Battery Weight	50 kg
Charging Temperature	0℃ ~ 45℃
Discharging Temperature	-20℃ ~ 60℃
Storage Temperature	-20℃ ~ 35℃
Battery Enclosure	Aluminum alloy housing
Protection Features	Short circuit protection, overcharge protection, over-discharge protection, over-temperature protection, overcurrent protection, ESD protection, and more
Application Fields	Energy storage systems, firefighting equipment / emergency systems, robotics, logistics vehicles / material handling equipment, and more

Product Features:

Durable Enclosure: Aluminum alloy housing provides enhanced reliability, structural strength, and durability in demanding applications
Easy Installation: Equipped with positioning holes and portable carrying handles for simple, secure, and reliable mounting
High-Reliability Output: Aviation-grade connectors ensure secure and dependable conductive connections
Comprehensive Protection Management: Utilizes specialized lithium battery protection ICs with high stability, precise monitoring, and accurate control, including temperature protection to eliminate potential safety hazards
Data Communication Management: RS485 communication enables precise data transmission, accurate temperature control, and real-time battery status monitoring, effectively minimizing potential safety risks
Optional Battery Switch: Can be equipped with a battery switch for controlled discharge output
Isolated Communication: BMS communication features optocoupler isolation for enhanced noise immunity and safety; RS485 bus supports customer-selectable communication at 250 kbps baud rate
High Performance: Safe and reliable discharge performance with extended cycle life
Environmentally Friendly: Long cycle life aligns with low-carbon, energy-saving, and sustainable value propositions
