Special Vehicle Battery Selection Table

Specifications

Special Vehicle — 51.2V Platform Model List

Voltage (V)	Capacity (Ah)	Weight (kg)	Matched Power (kW)	Dimensions (mm)	Communication	Certification	Remarks
51.2	80	52	4	435×375×244	RS485/CAN		Remote monitoring, GPS, heating function, voice alert optional. BMS functional safety report available; can quickly assist with UL/CE certification
51.2	105	48	4	470×375×245	RS485/CAN
51.2	108	62	5	514×375×255	RS485/CAN	UN38.3
51.2	130	73	5	514×429×255	RS485/CAN	UN38.3
51.2	150	75	5	514×429×256	RS485/CAN	UN38.3
51.2	150	50	5	878×308×318	RS485/CAN	UN38.3
51.2	186	102	7	545×390×320	RS485/CAN	UN38.3
51.2	230	105	7	735×335×270	RS485/CAN
51.2	270	135	12	1210×205×630	RS485/CAN
51.2	500	220	20	950×500×400	RS485/CAN
51.2	630	260	30	1560×480×380	RS485/CAN

Special Vehicle — 64V Platform Model List

Voltage (V)	Capacity (Ah)	Weight (kg)	Matched Power (kW)	Dimensions (mm)	Communication	Certification	Remarks
60	50	26	3	459×224×170	RS485/CAN		Remote monitoring, GPS, heating function, voice alert optional. BMS functional safety report available; can quickly assist with UL/CE certification
60	50	22	3	370×280×135	RS485/CAN	UN38.3
60	53	27	3	370×330×145	RS485/CAN
64	75	47	5	470×340×158	RS485/CAN
64	108	65	7	520×380×220	RS485/CAN
64	108	69	7	520×380×220	RS485/CAN
64	150	93	10	270×356×856	RS485/CAN	UN38.3
64	150	82	10	560×515×300	RS485/CAN
64	150	93.5	10	856×356×270	RS485/CAN
64	200	127	13	930×520×270	RS485/CAN
64	200	115	13	856×367×270	RS485/CAN

Special Vehicle — 72V Platform Model List

Voltage (V)	Capacity (Ah)	Weight (kg)	Matched Power (kW)	Dimensions (mm)	Communication	Certification	Remarks
72	100	48	7	340×250×272	RS485/CAN		Remote monitoring, GPS, heating function, voice alert optional. BMS functional safety report available; can quickly assist with UL/CE certification
72	100	43.5	7	250×285×340	RS485/CAN	UN38.3
72	150	111	11	560×426×322	RS485/CAN
72	300	200	22	1200×500×270	RS485/CAN
72	350	250	25	1200×500×270	RS485/CAN
72	500	300	35	901×571×280	RS485/CAN
72	525	330	38	770×460×530	RS485/CAN
