Industrial Energy Storage Battery

Specifications

Product Specification Sheet

Parameter	Specification
Cell Model	26700-16Ah-3.2V
Product Dimensions (L×W×H)	120 × 80 × 80 mm
Nominal Voltage	12.8 V
Nominal Capacity	16 Ah
Internal Resistance (Finished)	≤ 100 mΩ
Charge Voltage	14.4 V
Charge Current	≤ 30 A
Discharge Current	≤ 30 A
Discharge Cut-off Voltage	11.2 V
Battery Weight	1200 g (approx. 1.2 kg)
Charging Temperature	0℃ ~ 45℃
Discharging Temperature	-20℃ ~ 60℃
Storage Temperature	-20℃ ~ 35℃
Battery Encapsulation	Blue PVC heat-shrink film
Protection Features	Short circuit protection, overcharge protection, over-discharge protection, over-temperature protection, overcurrent protection, ESD protection, and more
Application Fields	Outdoor surveillance / security camera systems, portable backup power supplies, outdoor equipment, and various industrial devices

Product Features:

Simple & Reliable Encapsulation: Blue PVC heat-shrink film provides straightforward installation with reliable insulation and protection
Superior Shock & Vibration Resistance: Epoxy board insulation with precision laser-welded aluminum busbars ensures excellent anti-vibration and anti-shock performance
Comprehensive Protection Management: Utilizes specialized lithium battery protection ICs with high stability, precise monitoring, and accurate control, including temperature protection to eliminate potential safety hazards
LED Battery Level Indicator: Real-time battery status display for easy monitoring
Output Control Switch: Equipped with a low-voltage switch for convenient power output control
High Performance: Safe and reliable discharge performance with extended cycle life
Environmentally Friendly: Long cycle life aligns with low-carbon, energy-saving, and sustainable value propositions
