Industrial Robot Battery

Specifications

Product Specification Sheet

Parameter	Specification
Cell Model	LF105 / 52Ah / 3.2V
Battery Configuration	LF105-16S1P / 50Ah / 51.2V
Nominal Voltage	51.2 V
Nominal Capacity	50.0 Ah
Charge Voltage	58.4 V
Charge Current	≤ 25.0 A
Discharge Current	50.0 A
Instantaneous Discharge Current	70 A
Discharge Cut-off Voltage	40.0 V
Internal Resistance (Finished)	≤ 100 mΩ
Battery Weight	≤ 28.0 kg
Product Dimensions (L×W×H)	230 × 310 × 410 mm
Charging Temperature	0℃ ~ 55℃
Discharging Temperature	-20℃ ~ 55℃
Storage Temperature	-20℃ ~ 45℃
Battery Enclosure	Sheet metal housing
Protection Features	Intelligent BMS with power management (RS485 & CAN protocols), short circuit protection, overcharge protection, over-discharge protection, overcurrent protection, over-temperature protection, and more
Application Fields	Golf carts / buggies, robotics, UPS (uninterruptible power supplies), lawn mowers, and more

Product Features:

Low Standby Power Consumption: Optimized for energy efficiency during idle periods
Integrated Temperature Protection: Built-in temperature monitoring ensures safe operation under varied conditions
Reliable & Safe: Robust design with comprehensive BMS protection for enhanced safety and reliability
Extended Cycle Life: Long operational lifespan for reduced total cost of ownership
RS485 & CAN Communication: Standard interfaces for real-time data monitoring and system integration
Environmentally Friendly: Long cycle life aligns with low-carbon, energy-saving, and sustainable value propositions
