Industrial & Specialty Battery

Specifications

Product Specification Sheet

Parameter	Specification
Cell Model	32700-6Ah-3.2V
Battery Configuration	32700-4S10P-60Ah-12.8V
Product Dimensions (L×W×H)	290 × 200 × 90 mm
Nominal Voltage	12.8 V
Nominal Capacity	60 Ah
Internal Resistance (Finished)	≤ 150 mΩ
Charge Voltage	14.6 V
Charge Current	≤ 20 A
Discharge Current	≤ 20 A
Discharge Cut-off Voltage	10.0 V
Battery Weight	Approx. 4.0 kg (4000 g)
Charging Temperature	0℃ ~ 45℃
Discharging Temperature	-20℃ ~ 60℃
Storage Temperature	-20℃ ~ 35℃
Battery Enclosure	Aluminum alloy housing
Protection Features	Short circuit protection, overcharge protection, over-discharge protection, over-temperature protection, overcurrent protection, ESD protection, and more
Application Fields	Battery systems for intelligent management systems, industrial equipment, and more

Product Features:

Durable Enclosure: Aluminum alloy housing provides enhanced reliability and structural strength for demanding industrial applications
High Capacity: 60Ah capacity delivers extended runtime for intelligent management systems and industrial equipment
High-Performance Cells: 32700 cell platform with 6Ah capacity offers excellent energy density and reliable performance
Comprehensive Protection Management: Specialized lithium battery protection ICs with high stability, precise monitoring, and accurate control, including temperature protection to eliminate potential safety hazards
ESD Protection: Built-in electrostatic discharge protection safeguards sensitive electronics
Wide Operating Temperature Range: -20℃ to 60℃ discharge capability supports diverse industrial environments
Long Cycle Life: Extended operational lifespan reduces total cost of ownership
Environmentally Friendly: Long cycle life aligns with low-carbon, energy-saving, and sustainable value propositions
