Industrial LiFePO4 Battery

Specifications

Product Specification Sheet

Parameter	Specification
Cell Model	26700 / 3.2V / 4Ah
Battery Configuration	26700-8S5P / 25.6V / 20Ah
Nominal Voltage	25.6 V
Nominal Capacity	20 Ah
Charge Voltage	29.2 V
Charge Current	5 A
Discharge Current	10 A
Instantaneous Discharge Current	50 A (5s)
Discharge Cut-off Voltage	20 V
Internal Resistance (Finished)	≤ 200 mΩ
Battery Weight	1.7 kg
Product Dimensions (L×W×H)	280 × 130 × 80 mm (Max)
Charging Temperature	0℃ ~ 45℃
Discharging Temperature	-20℃ ~ 55℃
Storage Temperature	-20℃ ~ 40℃
Temperature Protection	60℃ ± 5℃
Battery Enclosure	Stainless steel housing
Protection Features	Short circuit protection, overcharge protection, over-discharge protection, overcurrent protection, temperature protection, battery level indication, low-battery alarm, and more
Application Fields	Wide range of applications including robotics, AGV, energy storage, portable equipment, and more

Product Features:

Comprehensive Protection Parameters: Equipped with short circuit protection, overcharge protection, over-discharge protection, overcurrent protection, temperature protection, battery level display, and low-battery alarm for enhanced safety and user awareness
Data Communication Management: RS485 communication interface with high-precision Seiko IC and TI charger management chips, ensuring precise data transmission and accurate temperature control to minimize potential safety risks
Safety & Reliability: Built to international standards with stable performance and extended cycle life
Long Cycle Life: Extended operational lifespan for reduced total cost of ownership
Environmentally Friendly: Long cycle life aligns with low-carbon, energy-saving, and sustainable value propositions
