BY200Z Outdoor Portable Power Station

Specifications

Product Specification Sheet

Parameter	Specification
Capacity	15,000mAh / 3.2V × 4 (45IP) — Actual total: 60,000mAh / 60Ah / 3.2V (45IP) ➔ 15Ah / 12.8V (192Wh)
Input	DC1, DC2, Cigarette lighter input: 14.6V / 10A charger input; Supports photovoltaic PWM tracking, max PV input 24V (DC5521 and cigarette lighter share same input — cannot connect different power sources simultaneously)
Type-C Output	QC3.0, max 12V / 1.5A (18W); PD, max 12V / 1.5A (18W)
USB-A1 Output	QC3.0, max 12V / 1.5A (18W)
USB-A2 & USB-A3 Output	Combined output: max 5V / 3A (15W)
DC Output (DC1, DC2)	12V / 10A (120W) max each
Cell Type	LiFePO₄ (Lithium Iron Phosphate) power cell 33140 (cylindrical)
Dimensions (L×W×H)	214 × 125 × 215 mm
Material	PC + V0 flame retardant
Color	Black / White (customizable)
Product Weight	Approx. 2.2 kg (subject to customization)
Packaging Dimensions (L×W×H)	280 × 177 × 390 mm

Features at a Glance:

High-capacity LiFePO₄ battery pack: 12.8V / 15Ah (192Wh) for reliable, long-lasting power
Multiple charging inputs: DC1/DC2, cigarette lighter, and PV solar input with PWM tracking
Versatile outputs: Type-C (PD/QC3.0), USB-A (QC3.0), standard USB-A, and DC12V ports
Supports fast charging for compatible devices
PC + V0 flame-retardant housing for enhanced safety
Compact and portable design with customizable color options
Ideal for outdoor activities, camping, emergency backup, and off-grid power needs
