Energy Storage Battery for Power & Telecom

Specifications

English Technical Specification Sheet

Item	Specification
Cell Model	26700 / 3.2V / 4.0Ah
Battery Pack Specification	26700-4S10P / 12.8V / 40Ah
Nominal Voltage	12.8V
Nominal Capacity	40Ah
Charging Voltage	14.4V
Charging Current	≤5A
Discharge Current	5A
Instantaneous Discharge Current	10A
Discharge Cut-off Voltage	10.0V
Internal Resistance	≤150mΩ
Battery Weight	4.0Kg
Product Dimensions	148 * 140 * 116 mm (Max)
Charging Temperature	0 ~ 45℃
Discharging Temperature	-20 ~ 60℃
Storage Temperature	-20 ~ 35℃
Battery Packaging	Sheet Metal Shell
Application Field	Communication equipment, Detection & Measurement/Control instruments, etc.
