Industrial Power Battery

Specifications

Product Specification Sheet

Parameter	Specification
Cell Model	18650 / 3.6V / 2500mAh
Battery Configuration	18650-7S6P / 25.2V / 15Ah
Nominal Voltage	25.2 V
Nominal Capacity	15 Ah
Charge Voltage	29.4 V
Charge Current	≤ 5 A
Discharge Current	5 A
Instantaneous Discharge Current	10 A
Discharge Cut-off Voltage	21.0 V
Internal Resistance (Finished)	≤ 100 mΩ
Battery Weight	Approx. 2.2 kg (2200 g)
Product Dimensions (L×W×H)	160 × 128 × 80 mm (Max)
Charging Temperature	0℃ ~ 45℃
Discharging Temperature	-20℃ ~ 60℃
Storage Temperature	-20℃ ~ 35℃
Battery Packaging	Blue PVC shrink-wrap
Protection Features	Short circuit protection, overcharge protection, over-discharge protection, overcurrent protection, and more
Application Fields	Fire protection equipment / firefighting apparatus, inspection and measurement instruments, test and control equipment, and more

Product Features:

Compact & Lightweight: Optimized form factor with low weight (2.2kg) for portable equipment applications
High Energy Density: 18650 cell platform provides reliable performance in a small footprint
Comprehensive Circuit Protection: Built-in BMS safeguards against overcharge, over-discharge, overcurrent, and short circuit conditions
Wide Operating Temperature Range: -20℃ to 60℃ discharge capability supports diverse operational environments
Easy Integration: Standard dimensions and connector options for seamless integration into fire protection and test equipment
Durable Construction: PVC packaging provides insulation and protection against environmental factors
