Instrumentation Battery

Specifications

English Technical Specification Sheet

Item	Specification
Cell Model	18650 / 3.6V / 2500mAh
Battery Pack Specification	18650-7S6P / 25.2V / 15Ah
Nominal Voltage	25.2V
Nominal Capacity	15Ah
Charging Voltage	29.4V
Charging Current	≤5A
Discharge Current	5A
Instantaneous Discharge Current	10A
Discharge Cut-off Voltage	21.0V
Internal Resistance	≤100mΩ
Battery Weight	2200g (2.2Kg)
Product Dimensions	160 * 128 * 80 mm (Max)
Charging Temperature	0 ~ 45℃
Discharging Temperature	-20 ~ 60 ℃
Storage Temperature	-20 ~ 35 ℃
Battery Packaging	Blue PVC
Application Field	Firefighting equipment, Detection & Measurement/Control instruments, etc.
