LiFePO4 Power Battery

Specifications

English Technical Specification Sheet

Item	Specification
Cell Model	26700 - 4000mAh - 3.2V
Battery Pack Specification	26700 - 16S4P - 16Ah - 48V
Product Dimensions	280 * 170 * 160 mm
Nominal Voltage	51.2V
Nominal Capacity	16Ah
Internal Resistance	≤200mΩ
Charging Voltage	58.4V
Charging Current	≤4.5A
Discharge Current	≤2.0A
Discharge Cut-off Voltage	40V
Battery Weight	7000g (7.0kg)
Charging Temperature	0 ~ 45℃
Discharging Temperature	-20 ~ 60℃
Storage Temperature	-20 ~ 35℃
Battery Casing	ABS+PC Shell / Aluminum Alloy Shell
Output Method	Aviation Plug
Application Field	Communication equipment, Portable communication equipment

Protection Type	Description
Lithium Battery Protection	Short circuit protection, Overcharge protection, Over-discharge protection, Overtemperature protection, Overcurrent protection, ESD (Electrostatic Discharge) protection, etc.
